Infrastructure

Two advanced manufacturing units in Rohtak. 4,500 MT/month combined capacity. One uncompromising standard.

CHQ wire drawing line inside Rohit Steels Unit 1
Unit 1 — CHQ Wire Drawing Line, Rohtak
Bright bar grinding and finishing line inside Rohit Steels Unit 2
Unit 2 — Bright Bar Finishing Line, IMT Rohtak

Unit 1 — CHQ Wire Rod Plant

Rohit Steels — Unit 1

H.O. & Correspondence Address, Plot No: 84-85-86-116, IDC Hisar Road, Rohtak, Haryana 124001

3,000 MT
per month — CHQ Wire Rods
Exterior of the Rohit Steels Unit 1 CHQ wire plant
Unit 1 — Hisar Road, Rohtak

CHQ Wire Production Process

Live production sequence

Stage 01 of 10 — Wire Rod

Wire Rod: Incoming coils are identified and prepared for controlled processing.

CHQ wire production process flow — wire rod, pickling & coating, drawing, annealing, intermediate inspection, skin pass, packing, shipment
CHQ Wire — End-to-End Production Flow

Capacity 4500 MT/Month

Pickling & Phosphating Line

Cleans the coil surface for the best possible drawing finish; lube coating extends the life of cold-forging dies at our customers.

01De-binding
02Acid Pickling
03Jet Washing
04Water Dipping
05Activation
06Phosphating
07D.M. Watering
08Bond Lube Coating
09Drying

Wire Drawing

Multi-Machine Drawing Lines

Automated wire drawing machine at Rohit Steels

Size range 1.9 mm – 40 mm across seven dedicated wire-drawing machines.

MachineMinMax
Wire Draw IVD-6003 mm7 mm
Wire Draw IVD-8005 mm13 mm
Wire Draw IVD-9008 mm20 mm
Wire Draw IVD-120020 mm40 mm
Wire Draw Bull Block16 mm28 mm
Wire Draw Bull Block (Mini)5 mm13 mm
Wire Draw 4-Block (Multi)1.9 mm7 mm
Bell-type spheroidized annealing furnace at Rohit Steels

Spheroidized Annealing — 1800 MT/Month

Bell-Type Annealing Furnaces

Real-time SCADA monitored annealing cycles operated by experienced supervisors — delivering consistent metallurgical quality across every batch.

30 Ton Furnace
USP of Rohit Steels
  • • 2 bases, 3 bells
  • • Wire size 3.50 mm – 36 mm, all grades
  • • Capacity up to 900 MT/month
  • • Large consistent-quality batches
7 Ton Furnace
Small batch flexibility
  • • 6 bases, 4 bells
  • • Wire size 2.30 mm – 30 mm, all grades
  • • Capacity up to 800 MT/month
  • • SCADA monitored cycles
Rohit Steels Unit 2 main entrance

Unit 2 — Bright & Ground Bar Plant

Rohit Steels — Unit 2

Plot No.: 14 & 25, 31B, Phase-I, HSIIDC, IMT, Garhi Bohar, Rohtak — 124021, Haryana

Established 2020 to serve growing precision-component industries. Currently producing ~1200 MT/month against installed capacity of 1500 MT/month.

1,500 MT
per month — Bright & Ground Bars

Bar Plant Production Process

Live production sequence

Stage 01 of 10 — Wire Rod

Wire Rod: Selected raw material is verified by grade and heat number.

Bright bar plant production process diagram — wire rod, annealing, drawing, pre-straightening, shot blast, descaler, grinding & polishing, inspection, packing, shipment
Bright Bar Plant — Production Diagram
Annealed BarPeeled & Ground BarBright BarHex BarProfile Bar

Combined Drawing Lines (CDL)

3 CDL machines + 2 shot-blasting draw bars (3–28 mm), 3 draw bench machines (22–60 mm), 3 band saws and straighteners. Newly added chamfering machine on customer demand.

Combined drawing line CDL machines at Unit 2
Old CDL Machine
Round7 – 13 mm
Hex6 – 13 mm
Drawing speed40 m/min
New Big CDL Machine
Round10 – 28 mm
Hex10 – 24 mm
Square10 – 24 mm
Drawing speed30 m/min
New Small CDL Machine
Round7 – 15 mm
Hex6 – 13 mm
Drawing speed50 m/min
Centerless grinding machine operator at Unit 2

Centerless Grinding & Polishing

3 centerless grinding machines for defect-free bar surfaces, followed by polish machines for a premium finish on machined components.

Bar storage racks at Rohit Steels under 5S discipline

Material Handling

Maintained under 5S discipline. Loading and unloading handled by automated EOT cranes of varying capacities.

Unit 1 — CHQ Wire Plant

  • Pickling & Phosphating (4500 MT/M)
  • 7 Wire Drawing Machines (1.9–40 mm)
  • Bell-type Spheroidized Annealing
  • Skin Pass & Final Inspection

Unit 2 — Bar Plant

  • 3 CDL + 3 Draw Bench Machines
  • Shot Blasting & Descaling
  • Centerless Grinding & Polishing
  • MPI Testing & Chamfering
